STEAM ROTARY JOINTS

RT-200-Series

  • Single and Dual Flow provision
  • Radial and axial housing connection
  • Self supported rotary joint
  • Easy and quick replacement of seals
  • Stainless steel internal parts
  • Consult factory for special applications
  • LH & RH – UNF Threads
  • LH & RH Metric Threads on the Rotor
  • BSP & NPT Threads on B-Port

Description

The Type RT-200 Series is steam rotary joints design is made in such form that repair can be done without dismounting from its application thus cost is very economical. Remove old rotary seal and floating seal group and replace them with new ones.Carbon graphite bush bearings ensures larger bearing area enabling the rotary union to function trouble free for long duration without lubrication. This product is particularly used in molding, plastic, iron & steel and pharmaceutical industries.

We also manufacture and supply Water Rotary Joint, High Temperature Rotary Joint and Hot Oil Rotary Joint as being topmost Rotary Joints manufacturers in Mumbai as well as known as one of the most precise rotary Joints manufacturing companies in India.

FAQ

  • It transfers steam between stationary piping and rotating equipment.
  • Commonly used in steam-heated rolls, dryers, calenders, paper and textile machinery.
  • It allows continuous steam supply and condensate removal during rotation.
  • Check steam pressure, temperature, RPM and flow requirement.
  • Confirm the shaft size, connection type and mounting arrangement.
  • For accurate selection, provide your machine or existing rotary joint specifications.
  • The joint can be designed to allow efficient condensate drainage from the rotating equipment.
  • Correct condensate removal helps maintain effective heat transfer.
  • The installation should follow the recommended steam and condensate flow arrangement.
  • Match the joint’s connection and shaft dimensions with the machine.
  • Connect the steam inlet and condensate outlet correctly.
  • Keep the piping properly supported and avoid excessive load on the rotary joint.
  • Check for leakage before putting the equipment into continuous operation.
  • Yes, replacement steam rotary joints can be supplied based on the existing unit.
  • Share the brand, model number, dimensions, photo or drawing.
  • The replacement can be matched according to steam pressure, temperature, RPM and fitting requirements.

Size

  • 1/4″ (DN08) – 4″ (DN100)

Parameter

  • Max. Pressure : 1 bar.
  • Max. Temperature : 120°C
  • Max. Speed : 3,500 rpm

Seal Faces  : Cabon, SiC and TC

Elastomer    : Viton, Neoprene, EPDM, NBR and Buna-N

MOC            : SS 316, Brass, Carbon Steel.

Threaded rotor Mono Flow and Dual flow

Quick release rotor Mono Flow and Dual flow

Flanged rotor Mono Flow and Dual flow
