HIGH TEMPERATURE ROTARY JOINTS

RT-500-Series

  • Single flow and Dual flow model
  • Self supported rotary joints
  • Chrome plated steel, cast iron & cast steel housing
  • Stainless steel rotors
  • Torque lugs on housing
  • Threaded and quick release and flange shaft alternatives
  • Seal wear indicator on shaft
  • Consult factory for special applications
  • Carbon graphite Bush Bearings / Seal rings and stainless steels springs.
  • Available with LH & RH BSP / NPT Threads on rotor and BSP & NPT Threads on B-Port

Description

The RT-500 Series is high temperature rotary joint designed for thermal oil and steam applications. The steel rotor supported on extra lengthcarbon graphite bush bearings ensures larger bearing area enabling the rotary joint to function trouble free for long durations without lubricationand can run up to 500rpm and 300°C.The special carbon graphite bearing is lubricated by the process fluid and requires no additional lubrication. This seal package combination provides for a long-lasting and low maintenance rotary union. These are high pressure-steam and high temperature hot oil rotary joints.

We also manufacture and supply Water Rotary Joint, Steam Rotary Joint, and Hot Oil Rotary Joint as being topmost Rotary Joints manufacturers in Mumbai as well as known as one of the most precise rotary Joints manufacturing companies in India.

FAQ

  • They transfer high-temperature fluids or thermal media between stationary and rotating equipment.
  • Commonly used in heating rolls, dryers, calender machines and industrial processing equipment.
  • They are designed to maintain reliable sealing under elevated temperatures.
  • Check operating temperature, pressure, RPM and fluid type.
  • Also confirm shaft size, connection type and mounting dimensions.
  • For accurate selection, provide your machine or existing rotary joint specifications.
  • The maximum temperature depends on the joint design, sealing materials and operating medium.
  • High-temperature applications require suitable seals and materials to prevent premature wear.
  • The rotary joint should always be selected according to the actual working temperature.
  • Match the shaft and connection dimensions before installation.
  • Connect the inlet and outlet according to the required flow direction.
  • Keep the joint correctly aligned and avoid excessive pipe or mechanical load.
  • Check for leakage before starting continuous operation.
  • Yes, replacement joints can be supplied according to an existing brand, model or specification.
  • Share the model number, dimensions, photo or drawing of the existing joint.
  • Selection can be matched to temperature, pressure, RPM, fluid and fitting requirements.

Size

  • 1/4″ (DN08) – 4″ (DN100)

Parameter

  • Max. Pressure : 17 bar.
  • Max. Pressure : 17 bar.
  • Max. Pressure : 17 bar.
  • Max. Pressure : 28 bar.
  • Max. Temperature : 200°C
  • Max. Speed : 400 rpm
  • Do not work with max. pressure at max. speed.

Seal Faces  : Cabon

Elastomer    : GFT, PTFE, Graphoil

MOC            : SS 316, Brass, Carbon Steel.

Threaded rotor Mono Flow and Dual flow

Quick release rotor Mono Flow and Dual flow

Flanged rotor Mono Flow and Dual flow
